CHAPTER 1
DynoWare RT Electronics
DynoWare RT Upgrade for Model 424x Dynamometers Installation Guide
1-4
DYNOWARE RT ELECTRONICS
The DynoWare RT electronics consists of a main module and a speed pickup. Optional
modules include the Air Fuel Ratio (AFR) module and the Eddy Current Brake (ECB)
driver. Use this section to identify the modules and connections. More detailed
information for configuring the DynoWare RT electronics can be found in the
Power Core Help.
Figure 1-1: DynoWare RT Electronics
air fuel ratio
module
eddy current
brake driver
main module
speed pickup
