DynoWare RT Upgrade for Model 424x Dynamometers Installation Guide
CHAPTER 2
M ODEL 424 D YNO W ARE RT U PGRADE
WITHOUT E DDY C URRENT B RAKE
This chapter will walk you through removing the DynoWare EX and installing the
DynoWare RT upgrade on your model 424 Dynojet Dynamometer without the eddy
current brake. To ensure safety and accuracy in the procedures, perform the
procedures as they are described.
This chapter is divided into the following categories:
• Unpacking the DynoWare RT Parts, page 2-2
• Remove the DynoWare EX Electronics, page 2-3
• DynoWare RT Installation, page 2-8
• Cable Routing, page 2-10
• Testing, page 2-17
• Replace Covers, page 2-18
