CHAPTER 3
Unpacking the DynoWare RT Parts
DynoWare RT Upgrade for Model 424x Dynamometers Installation Guide
3-2
UNPACKING THE DYNOWARE RT PARTS
Carefully remove the following parts, verify the contents, and set aside.
part description part description
nut, 8-32, lock washer (8)
P/N 134490301
vehicle grounding kit
P/N 76100015
screw, 4-40 x 1/4", ph-pan,
zinc (8)
P/N 1904004
CAN termination plug
P/N 76423045
bracket, eddy current brake
driver (4)
P/N 21200068
primary inductive
pickup (2)
P/N 76950201
power cord, 125V, 10A
P/N 318110301
secondary inductive
pickup (2)
P/N 76950203
network cable
P/N 42900000
cable, speed pickup/brake,
35' (2)
P/N 76950547
connector
P/N 44329902
cable, IR temp sensor (2)
P/N 76950628
socket (2)
P/N 44359120
cable, load cell (2)
P/N 76950629
To Next Page
