BASIC DYNO OPERATION
Grounding the Vehicle
Version 5 DynoWare RT Upgrade for Model 424x Dynamometers Installation Guide
GROUNDING THE VEHICLE
You will need to ground the vehicle to the dyno before every run. Use the following
steps to install the grounding bracket and ground the vehicle to the dyno.
Never operate the dyno without first grounding the vehicle to the dyno.
You will need the following parts:
• 21600084 Grounding Bracket
• 36560834 Screw, 1/4-20 x 1/2"
• 76950788 Vehicle Grounding Cable
1 Choose any location on your dyno with a black 1/4-20 x 5/8-inch torx screw that
threads directly into the sheet metal and remove this screw.
2 Secure the grounding bracket to this location using one 1/4-20 x 1/2-inch screw.
3 Attach the vehicle ground cable to an exhaust bolt or engine bolt on the vehicle.
4 Attach the vehicle ground cable to the grounding bracket.
