CHAPTER 2
Replace Covers
DynoWare RT Upgrade for Model 424x Dynamometers Installation Guide
2-20
INSTALLING THE LOGO PANEL—ABOVE GROUND DYNOS
1 Secure each logo panel using the five screws removed earlier.
2 Replace the bridge covers if removed.
Figure 2-17: Install the Logo Panels
logo panel
bridge covers
