CHAPTER 3
Unpacking the DynoWare RT Parts
DynoWare RT Upgrade for Model 424x Dynamometers Installation Guide
3-4
The following parts are included in the DynoWare RT Speed Upgrade Kit P/N 78100057
inner bracket, speed pickup
card
P/N 21600085
screw, 1/4-20 x 1-1/8",
socket-head (2)
P/N 36562094
outer bracket, speed pickup
card
P/N 21600086
screw, mach 8-32 x 1/2" (8)
P/N 8-32 X .5 SCREW
split disk (2)
P/N 22300009
nut, 3/8-16, hex (2)
P/N DM150-011-004
split hub (2)
P/N 22400016
bolt, 3/8-16 x 1", hex (2)
P/N DM150-019-012
part description part description
