CHAPTER 3
Load Cell Calibration
DynoWare RT Upgrade for Model 424x Dynamometers Installation Guide
3-32
8 Place the weights towards the rear of the vehicle.
Note: Calibration arm placement determines positive direction for torque. Place
the weights towards the rear of the vehicle.
Refer to step 9 and Figure 3-29 on page 3-33 for calibration arm installation
instructions.
Figure 3-28: Calibration Bar Placement
direction of rotation
direction of
rotation
direction of
torque
