REV30 8.4.15 TT4-8 4TNV98
POWER TRAIN
Item Part Number Qty. Description
1 NPN 4 SHCS, M12X1.75 X 40, GR 10.9
TT08-54-003-KA 1 TRANSMISSION - AWD 2
TT08-54-005-KA 1 TRANSMISSION - 2WD 2
3 NPN 8 HCS, M12X1.75 X 25, GR 10.9, ZN PLATED
4 TM27C00305-ID 1 FLEX PLATE WASHER
5 B-TT10TD-00016-ID 1 FLEX PLATE
6 NPN 3 HCS, M16X2.0 X 45
7 NPN 3 LOCK WASHER, M16
8 B-TT5D-00017-4TNV 1 FLEX PLATE ADAPTER
9 5240849 2 TRANS DOWEL PIN
10 NPN 12 FHCS, M10X1.50 X 45, GR 10.9
11 B-TT10TD-00001-4TNV 1 TRANS PLATE
12 129953-21570 1 FLY WHEEL ASSEMBLY (CONTAINS ITEM 13)
13 129900-21600 1 RING GEAR (INCLUDED IN ITEM 12)
14 B-TT10TD-00002 1 TRANS PLATE SPACER
15 129916-01790 1 OIL SEAL
16 NPN 3 HCS, M10X1.5 X 45, GR 10.9, ZN PLATED
17 TMD27B00521-4TNV 1 ENGINE PLATE
18 41HN28 3 ADJ PLATE DOWEL PIN, 3/8 X 2.5
19 NPN 9 HCS, M10X1.5 X 35, GR 10.9, ZN PLATED
20 129940-77010 1 STARTER
21 NPN 2 HCS, M12X1.75 X 25
22 TMD27B00521-T3SPEC 1 ENGINE PLATE
23 NPN 4 HCS, M10X1.5 X 12
24 NPN 6 HCS, M8X1.25 X 12
25 121850-21130 6 HCS, M14X1.5 X 35 (INCLUDED WITH ENGINE)
