Eaton PowerXL DH1 - Table 188. Smartwire-DT Parameters

155
SmartWire-DT External Communication Cards
POWERXL SERIES VFD MN040010EN—June 2018 www.eaton.com
Table 188. SmartWire-DT parameters
Code Parameter Min. Max. Unit Default ID Note
B19 Terminal: SWD
B19.1 Monitor
B19.1.1 Device Parameters
BX.1.1.1 Board Status 0 B0 = DCOM Comm. Fault
B1 = Board HW Fault
B2 = NA for SMDT card
B3 = Fieldbus Fault
B4 = Reserved
BX.1.1.2 Firmware Version V1.01.0009
BX.1.1.3 Protocol Status 0 0=Not Configured
1=Operational
2=Diagnostics
BX.1.1.4 Operation Mode 0 0=PD2x16Bit Profile
1=8Bit Profile
2=1-0-A Switch
BX.1.1.5 PDP-Telegram Selection 1 1 1 1=Standard Telegram 1
BX.1.1.6 Fault Counter PDP 0 65535
BX.1.1.7 Fault Situations Max 8x8
BX.1.1.8 PDP-Profil Number 341
BX.1.1.9 PDP-Control Word 0x0000 0xFFFF
BX.1.1.10 PDP-Status Word 0x0000 0xFFFF
BX.1.2 Parameter Access
BX.1.2.1 PDP-MaxBlockLength 30
BX.1.2.2 PDP-NoOfMultiparameter 1
BX.1.2.3 PDP-MaxLatency 2
BX.1.3 DO Identification
BX.1.3.1 PDP-DO Manufacturer 0x019D
BX.1.3.2 PDP-DO Device Type 0x3000
BX.1.3.3 PDP-DO FW-Interface 01.03
BX.1.3.4 PDP-DO FW-Year 2017
BX.1.3.5 PDP-DO FW-DayMonth 1602
BX.1.3.6 PDP-DO NoOfDOs 1
BX.1.3.7 PDP-DO Subclass 1
BX.2 Parameters
BX.2.3 SWD. Card FB Fault Response 0 1 0
