IGNITION SYSTEM
14
CS-2511WES
251Ws
3 IGNITION SYSTEM
(A) Ignition switch
(B) Spark plug
(C) Spark plug cap coil
(D) Spark plug cap
(E) Ignition coil
(F) Bolt (M4)
(G) Collar
(H) Flywheel
(J) Nut (M8)
(K) Woodruff key
(B)
(C)
(D)
(E)
(H)
(J)
(F)
(A)
(G)
(K)
