Installation and Startup of UA 300 D
30
Version 2.03 27. Juni 2008
6. Press the ESC key twice to exit Menu 1 Configuration.
Choose 3 Clock − 2 Defrost Timer.
Enter the relevant parameters in the following screen.
3 Clock − 2 Defrost Timer
Defrost Timer XXX Select defrosting by external or internal defrost timer
Safe Defr Time XXX m Safe defrost time; defrost duration does not extend beyond this time
Defr. 1 xxxxx hh:mm
Enter defrost times
Defr. 2 xxxxx hh:mm
...
Defr. 14 xxxxx hh:mm
Manual Defrost XXX Manual defrosting ON/OFF
7 Press the ESC key to exit Menu 2 Defrost Timer.
8. Choose Menu 3 Setpoint Toggle:
Enter the relevant parameters in the following screen.
3 Clock − 3 Setpoint toggle
Status XXX
Toggle Setp. XXX Select INT, EXT, −−−: Internal, external, deactivated setpoint toggle
Blind On Time X s Enter night blind run time for refrigerated multidecks
Alt ON: xxxxx hh:mm
Enter time for setpoint toggle
AltOFF: xxxxx hh:mm
9. Press the ESC key twice to exit Menu 3 Setpoint Toggle.
10. Choose Menu 6 Configuration − 2 Controller
6 Configuration − 2 Controller
1 Type and Version Type, serial number and master−slave (ON/OFF)
2 Temp. Display Matching of displayed temperature
3 Alarm Delay Enter alarm time delay
4 230V Inputs 230 V inputs
5 Sensor Type Select temperature sensor type
11. Choose Menu 3 Alarm Delay.
6 Configuration − 2 Controller −
3 Alarm Delay
Sensor Fault XX m Alarm delay on sensor break
High/Low Temp. XX m Alarm delay on high or low temperature
No Defrost XX h Alarm is generated if defrosting does not take place within the set time
Selfholding X NO: Automatic reset of non−transient alarms
YES: Alarms must be reset manually
