Menu structure UA 300 D Controller type UA 111 XP
66
Version 2.03 27. Juni 2008
7.2.1 Menu 0 Main menu
REFR. PT. POS: XXXXX
1 Actual Values Continue to Screen 1
2 Setpoints Continue to Screen 2
3 Clock Continue to Screen 3
4 Messages Continue to Screen 4
5 Archive Continue to Screen 5
6 Configuration Continue to Screen 6
7.2.2 Menu 1 Actual Values
Actual Values POS: XXXXX
1 Temp. Sensor Continue to Screen 1−1
2 Cooling Zone 1 Continue to Screen 1−2
3 Defrost Zone 1 Continue to Screen 1−3
4 Not used with this controller type
5 Alarm Continue to Screen 1−5
6 Compressor Continue to Screen 1−6
7 Cooling Zone 2 Continue to Screen 1−7: Menu item is shown only when two−zone operation is set (Screen
6−1).
8 Defrost Zone 2 Continue to Screen 1−8: Menu item is shown only when two−zone operation is set (Screen
6−1).
S Screen 1−1 Temp. Sensor
TEMPERATUR POS: XXXXX
Temp. R2.1 XXX °C Current supply air temperature Input Z11/Z12
Temp. R4.1 XXX °C Current return air temperature Input Z21/Z22
Temp. R2.2 XXX °C Current supply air temperature Input Z31/Z32
Temp. R2.3 XXX °C Current supply air temperature Input Z41/Z42
Temp. R2.4 XXX °C Current supply air temperature Input Z51/Z52
Temp. R2.5 XXX °C Current supply air temperature Input Z61/Z62
Temp. R2.6 XXX °C Current supply air temperature Input Z71/Z72
Temp. R2.7 XXX °C Current supply air temperature Input Z81/Z82
Temp. R2.8 XXX °C Current supply air temperature Input Z91/Z92
Temp. R4.8 XXX °C Current return air temperature Input Z01/Z02
