Menu structure UA 300 D Controller type UA 111 X
51
E 2007 − ECKELMANN | BERLINER STRASSE 161 | 65205 WIESBADEN | FON +49(0)611 7103-0 | FAX 49(0)611 7103-133 | eckelmann.de
Version 2.03 27. Juni 2008
7.1.1 Menu 0 Main menu
REFR. PT. POS: XXXXX
1 Actual Values Continue to Screen 1
2 Setpoints Continue to Screen 2
3 Clock Continue to Screen 3
4 Messages Continue to Screen 4
5 Archive Continue to Screen 5
6 Configuration Continue to Screen 6
7.1.2 Menu 1 Actual Values
Actual Values POS: XXXXX
1 Temp. Sensor Continue to Screen 1−1
2 Cooling Zone 1 Continue to Screen 1−2
3 Defrost Zone 1 Continue to Screen 1−3
4 Not used with this controller type
5 Alarm Continue to Screen 1−5
6 Compressor Continue to Screen 1−6
7 Cooling Zone 2 Continue to Screen 1−7: Menu item is shown only when two−zone operation is set
(Screen 6−1).
8 Defrost Zone 2 Continue to Screen 1−8: Menu item is shown only when two−zone operation is set
(Screen 6−1).
