Menu structure UA 300 D Controller type UA 111 X
52
Version 2.03 27. Juni 2008
S Screen 1−1 Temp. Sensor
TEMPERATUR POS:XXXXX
Temp. R2.1 XXX °C Current supply air temperature Input Z11/Z12
Temp. R4.1 XXX °C Current return air temperature Input Z21/Z22
Temp. R2.2 XXX °C Current supply air temperature Input Z31/Z32
Temp. R2.3 XXX °C Current supply air temperature Input Z41/Z42
Temp. R2.4 XXX °C Current supply air temperature Input Z51/Z52
Temp. R2.5 XXX °C Current supply air temperature Input Z61/Z62
Temp. R2.6 XXX °C Current supply air temperature Input Z71/Z72
Temp. R2.7 XXX °C Current supply air temperature Input Z81/Z82
Temp. R2.8 XXX °C Current supply air temperature Input Z91/Z92
Temp. R4.8 XXX °C Current return air temperature Input Z01/Z02
S Screen 1−2 Cooling Zone 1
COOLING 1 POS:XXXXX
Cooling XXX Current ON/OFF status of cooling Zone 1 Terminals 25/26/28
Run Time XX % Cooling relay on time during last day (00:00 − 24:00 hours)
Starts X Cooling relay actuations during last day
Setpoint R2.x XXX °C Supply air temperature setpoint for comparison
Hystersis R2.x XXX K Supply air temperature hysteresis setpoint
Antifreeze XXX °C Antifreeze protection temperature limit
Hystersis anti XXX K Antifreeze protection hysteresis
S Screen 1−3 Defrost Zone 1
DEFROST 1 POS:XXXXX
Defrost 1 XXX Current ON/OFF status of defrosting Zone 1
Def. End. Tmp. XXX °C Defrost termination temperature for comparison
Last DefrstWe XX hh:mm Day and time of last defrost cycle started
S Screen 1−4 Not used with this controller type.
