ECKELMANN UA 300 D - Menu 6 Configuration

Menu structure UA 300 D Controller type UR 141
91
E 2007 − ECKELMANN | BERLINER STRASSE 161 | 65205 WIESBADEN | FON +49(0)611 7103-0 | FAX 49(0)611 7103-133 | eckelmann.de
Version 2.03 27. Juni 2008
*) Status abcdef covers following states of the refrigeration point. Display will be " − " if state is not
active.
Two−zone operation Single−zone operation
a O = Operating O = Operating
b R = Cooling R = Cooling
c R = Cooling D = Defrost
d D = Defrost G = Door (coldroom ctrlr. only)
e G = Door (coldroom ctrl. only) A = Alarm
f A = Alarm
7.3.7 Menu 6 Configuration
CONFIGURAT POS: XXXXX
1 Refrger. Point Continue to Screen 6−1
2 Controller Continue to Screen 6−2
3 Cooling Continue to Screen 6−3
4 Language Continue to Screen 6−4
S Screen 6−1 Refrger. Point
REFR. PT. POS: XXXXX Entry Default
Refriger. Point Name: Text only
xxxxxxxxxxxxxxx Free text entry describing refrigeration point (see note follo-
wing table)
Coldroom
controller
Item ID: XXXXX Free text entry displayed in screens after ITEM ID (see
note following table)
UA300
Priority: XX Alarm priority in failure of refrigeration point or when global
controller priority is set (Screen 6−5)
↑, ↓,
or numbers
(0..99)
1
Refr. Sys. No.: XX No. of pack controller allocated to case/coldroom controller ↑, ↓,
or numbers
(−−, 1..9)
1
Refr. Sys. Type: XXX Associated compressor pack.
Parameter only required when linked to a VS 3000 BS
having several zones. If a different type of pack controller
is used, set this parameter blank (−−−)
↑, ↓,
or numbers
(−−−, Z1, Z2)
−−−
No. Sensors XX Number of temperature sensors connected. After entering
↵ sensor scan is performed to redetermine the number of
sensors.
↵
Temp. Zones X Number of temperature zones:
Single−zone operation/
Two−zone operation
↑, ↓,
or numbers
(1, 2)
2
