4.3.4 Setting basic parameters
The following items 1 to 4 are only necessary for operation via CAN bus. Proceed to item 5 if the controller is to
be operated by a local setup unit (BT 300 x).
The menus shown below are intended as a guide only and may differ for certain controller types.
Please see Section Menu Structure for a detailed overview.
1. Cancel entry block (only controllers with CAN bus connection can be operated by the CI 3000/AL 300):
In the Main Menu
− Choose 9 Parameter Setting − 3 Block.
− Press the ENTER key (↵ ) to set the check mark ( √ ).
This cancels entry block, allowing settings to be made.
− Press the ESC key twice to exit the screen and return to the Main Menu.
Entry block is automatically activated if no key is pressed for 10 minutes and when switching on the
operator terminal.
2. In the main menu of CI 3000 Store Computer or AL 300 Operator Terminal:
Choose 5 Remote Operation.
3. Select case controller:
In the selection list, select the UA 300 D case controller to be set by its Node No. (Nd.nnn = 1 to 99),
either by using the cursor or typing in direct. Press the ENTER key (↵ ) to confirm. This displays the
main menu of the UA 300 D case controller.
4. In the main menu of the UA 300 D case controller:
First define the pack number and compressor pack:
5. Configuration – Select refrigeration point (Menu 6−1)
Various parameters can be entered and checked to define the refrigeration point to be controlled by
the UA 300 D:
6 Configuration − 1 Refrigeration
Point
Refr. Pt. Name:
Check name of refrigeration point (can only be edited on Store Computer)
xxxxxxxxxxxxxxx
Item ID: XXXXX Check position of refrigeration point (can only be edited on Store Computer)
Priority: XX Alarm priority 0 to 99 (See notes in Section 8.1 Alarms)
Refr. Sys. No.: XX No. of compressor pack supplying refrigeration point (1 to 9, important when several
compressor packs are used)
Refr. Sys. Type XXX Zone of compressor pack supplying refrigeration point (Z1/Z2, with VS 3000 BS
only)
Temp. Zones X Division of refrigeration point in one zone (tandem mode) or two zones
No. Sensors XX Number of sensors. The number of sensors connected is scanned on exiting the
parameter by pressing ENTER.
