Menu structure UA 300 D Controller type UR 141
84
Version 2.03 27. Juni 2008
7.3.3 Menu 2 Setpoints
SETPOINTS POS: XXXXX
1 Cooling Continue to Screen 2−1; Special case: when single−zone operation is set (Screen 6−1) and
setpoint toggle is disabled (Screen 3−3) Continue to Screen 2−1−1
2 Defrost Continue to Screen 2−2; Special case: when single−zone operation is set (Screen 6−1) and
setpoint toggle is disabled (Screen 3−3) Continue to Screen 2−2−1
3 Fans Continue to Screen 2−3; Special case: when single−zone operation is set (Screen 6−1) and
setpoint toggle is disabled (Screen 3−3) Continue to Screen 2−3−1
4 Alarm Continue to Screen 2−4; Special case: when single−zone operation is set (Screen 6−1) and
setpoint toggle is disabled (Screen 3−3) Continue to Screen 2−4−1
S Screen 2−1 Cooling
COOLING POS: XXXXX
1 Zone 1 Continue to Screen 2−1−1
2 Zone 2 Continue to Screen 2−1−2; shown only when two−zone operation is set (Screen 6−1)
3 Zone 1A Altern. Continue to Screen 2−1−3; shown only when setpoint toggle is enabled (Screen 3−3)
4 Zone 2A Altern. Continue to Screen 2−1−4; shown only when two−zone operation is set (Screen 6−1) and only
when setpoint toggle is enabled (Screen 3−3)
S Screen 2−1−1 Zone 1
COOLING 1 POS: XXXXX Entry Default
Setpoint R4.1 XXX °C Room air sensor setpoint −45..30 −18 °C
Hystersis R4.1 X K Room air sensor hysteresis setpoint 1..8 2 K
S Screen 2−1−2 Zone 2
Shown only when two−zone operation is set (Screen 6−1).
COOLING 2 POS: XXXXX Entry Default
Setpoint R4.3 XXX °C Room air sensor setpoint −10..30 0 °C
Hystersis R4.3 X K Room air sensor hysteresis setpoint 1..8 2 K
S Screen 2−1−3 Zone 1A Altern.
Shown only when two−zone operation is set (Screen 3−3).
COOLING 1A POS: XXXXX Entry Default
Setpoint R4.1 XXX °C Room air sensor setpoint −45..30 −18 °C
Hystersis R4.1 X K Room air sensor hysteresis setpoint 1..8 2 K
