Menu structure UA 300 D Controller type UR 141
83
E 2007 − ECKELMANN | BERLINER STRASSE 161 | 65205 WIESBADEN | FON +49(0)611 7103-0 | FAX 49(0)611 7103-133 | eckelmann.de
Version 2.03 27. Juni 2008
S Screen 1−6 Not used with this controller type
S Screen 1−7 Cooling Zone 2
COOLING 2 POS: XXXXX
Cooling XXX Current ON/OFF status of cooling Zone 2 Terminals 35/36/38
Run Time XX % Cooling relay on time during last day (00:00 − 24:00 hours)
Starts X Cooling relay actuations during last day
Temp. R4.3 XXX °C Room air sensor R4.3 setpoint for comparison
Setpoint R4.3 XXX °C Room air sensor R4.3 setpoint
Hystersis R4.3 XXX K Room air sensor R4.3 hysteresis
S Screen 1−8 Defrost Zone 2
DEFROST 2 POS: XXXXX
Counting Rate X Counting rate
Defrost Counter X Defrost counter
Defrost 2 XXX Current ON/OFF status of defrosting Zone 2 Terminals 53/54
Temp. R1.3 XXX °C Current temperature on evaporator sensor R1.3
Temp. R1.4 XXX °C Current temperature on evaporator sensor R1.4
Def. End. Tmp. XXX °C Defrost termination temperature for comparison
Wait Time XX m Waiting time setpoint
Drip Time XX m Drip time setpoint
Last DefrstWe XX hh:mm Day and time of last defrost cycle started
S Screen 1−9 Fans Zone 2
FANS 2 POS: XXXXX
Fans XXX Current ON/OFF status of fan Zone 2 Terminals 73/74
Temp. R1.3 XXX °C Current temperature on evaporator sensor R1.3
Fan Delay XX °C Fan delay
