ECKELMANN UA 300 D - Menu 5 Archive; Menu 6 Configuration

Menu structure UA 300 D Controller type UA 111 X
60
Version 2.03 27. Juni 2008
S Screen 4−3 Delete messages
MESSAGES POS: XXXXX Entry
Delete !
Are you sure ?
NO: ESC YES: ↵
Safety prompt for deleting messages;
press ESC to go back after cancelling messages
↵, ESC
7.1.6 Menu 5 Archive
ARCHIVE POS: XXXXX
dd.mm.yy hh:mm Time of archiving Record 1
Zone 1: abcdef x °C Status and temperature of Zone 1, see Note *)
Zone 2: abcdef x °C Status and temperature of Zone 2, see Note *); shown only when two−zone operation is set
(Screen 6−1)
...
dd.mm.yy hh:mm Time of archiving Record n
Zone 1: abcdef x °C Status and temperature of Zone 1, see Note *)
Zone 2: abcdef x °C Status and temperature of Zone 2, see Note *); shown only when two−zone operation is set
(Screen 6−1)
*) Status abcdef covers following states of the refrigeration point. Display will be " − " if state is not
active.
Two−zone operation Single−zone operation
a O = Operating O = Operating
b R = Cooling R = Cooling
c R = Cooling D = Defrost
d D = Defrost G = Door (coldroom ctrlr. only)
e G = Door (coldroom ctrl. only) A = Alarm
f A = Alarm
7.1.7 Menu 6 Configuration
CONFIGURAT POS: XXXXX
1 Refriger. Point Continue to Screen 6−1
2 Controller Continue to Screen 6−2
3 Cooling Continue to Screen 6−3
4 Language Continue to Screen 6−4
