7.3.1 Menu 0 Main menu
REFR. PT. POS: XXXXX
1 Actual Values Continue to Screen 1
2 Setpoints Continue to Screen 2
3 Clock Continue to Screen 3
4 Messages Continue to Screen 4
5 Archive Continue to Screen 5
6 Configuration Continue to Screen 6
7.3.2 Menu 1 Actual Values
Actual Values POS: XXXXX
1 Temp. Sensor Continue to Screen 1−1
2 Cooling Zone 1 Continue to Screen 1−2
3 Defrost Zone 1 Continue to Screen 1−3
4 Fans Zone 1 Continue to Screen 1−4
5 Alarm Continue to Screen 1−5
6 Not used with this controller type
7 Cooling Zone 2 Continue to Screen 1−7: Menu item is shown only when two−zone operation is set
(Screen 6−1).
8 Defrost Zone 2 Continue to Screen 1−8: Menu item is shown only when two−zone operation is set
(Screen 6−1).
9 Fans Zone 2 Continue to Screen 1−9: Menu item is shown only when two−zone operation is set
(Screen 6−1).
S Screen 1−1 Temp. Sensor
TEMPERATUR POS: XXXXX
Temp. R4.1 XXX °C Current room air sensor temperature Input Z21/Z22
Temp. R1.1 XXX °C Current evaporator sensor temperature Input Z31/Z32
Temp. R4.2 XXX °C Current room air sensor temperature Input Z41/Z42
Temp. R1.2 XXX °C Current evaporator sensor temperature Input Z51/Z52
Temp. R4.3 XXX °C Current room air sensor temperature Input Z71/Z72
Temp. R1.3 XXX °C Current evaporator sensor temperature Input Z81/Z82
Temp. R4.4 XXX °C Current room air sensor temperature Input Z91/Z92
Temp. R1.4 XXX °C Current evaporator sensor temperature Input Z01/Z02
To Next Page
