ECKELMANN UA 300 D - Menu 4 Messages

Menu structure UA 300 D Controller type UA 111 XP
74
Version 2.03 27. Juni 2008
S Screen 3−3 Toggle Setpoints
TOGGLE POS: XXXXX Entry Default
Status XXX Setpoint toggle status (OFF/ON) of alternative set of setpo-
ints (setpoint toggle)
Toggle Setp. XXX Setpoint toggle via input D21/22 (EXT), internal (INT) or
disabled (−−)
↑, ↓,
(EXT, INT, −−)
EXT
Blind On Time X s Fan and cooling stop time after toggling to alternative set of
setpoints with external setpoint toggle (Screen 3−3)
0..250 55 sec
Alt ON: DD−DD hh:mm Start time for toggle to alternative set of sepoints; weekday
from−to TT−TT, time hh:mm; shown only when internal set-
point toggle is activated (Screen 3−3)
↑, ↓,
(Mo−Su etc.)
or numbers
(hh:mm)
−−
Alt OFF: DD−DD hh:mm End time for toggle to alternative set of sepoints; weekday
from−to TT−TT, time hh:mm; shown only when internal set-
point toggle is activated (Screen 3−3)
↑, ↓,
(Mo−Su etc.)
or numbers
(hh:mm)
−−
... A total of 7 different ON and OFF toggle times can be defi-
ned. A toggle time will only be obeyed when a matched
pair of on and off times is set as a parameter.
7.2.5 Menu 4 Messages
MESSAGES POS: XXXXX Entry
1 View Continue to Screen 4−1 Show message log 1
2 Acknowledge Messages in message log are cancelled; alarms are cancelled after being
shown: press ESC to go back
2
3 Delete Continue to Screen 4−3 3
S Screen 4−1 View messages
MESSAGES POS: XXXXX
Error Message 1: Fault 1 message text
dd.mm.yy hh:mm ON Start of Fault 1
dd.mm.yy hh:mm OFF End of Fault 1 (only when Fault 1 terminated)
...
Error Message n: Fault n message text
dd.mm.yy hh:mm ON Start of Fault n
dd.mm.yy hh:mm OFF End of Fault n (only when Fault n terminated)
S Screen 4−2 Acknowlegde messages
Alarms Cancelled! is displayed. Alarms Cancelled! is displayed.
