Menu structure UA 300 D Controller type UA 111 X
54
Version 2.03 27. Juni 2008
7.1.3 Menu 2 Setpoints
SETPOINTS POS: XXXXX
1 Cooling Continue to Screen 2−1; Special case: Move to Screen 2−1−1 when single−zone operation is
set (Screen 6−1) and setpoint toggle is disabled (Screen 3−3)
2 Defrost Continue to Screen 2−2; Special case: Move to Screen 2−2−1 when single−zone operation is
set (Screen 6−1) and setpoint toggle is disabled (Screen 3−3)
3 Not used with this controller type
4 Alarm Continue to Screen 2−4; Special case: Move to Screen 2−4−1 when single−zone operation is
set (Screen 6−1) and setpoint toggle is disabled (Screen 3−3)
5 Compressor Continue to Screen 2−5
S Screen 2−1 Cooling
COOLING POS: XXXXX
1 Zone 1 Continue to Screen 2−1−1
2 Zone 2 Continue to Screen 2−1−2; shown only when two−zone operation is set (Screen 6−1)
3 Zone 1A Altern. Continue to Screen 2−1−3; shown only when setpoint toggle is enabled (Screen 3−3)
4 Zone 2A Altern. Continue to Screen 2−1−4; shown only when two−zone operation is set (Screen 6−1) and only
when setpoint toggle is enabled (Screen 3−3)
S Screen 2−1−1 Zone 1
COOLING 1 POS: XXXXX Entry Default
Setpoint R2.x XXX °C Supply air temperature setpoint −10..20 −3 °C
Hystersis R2.x X K Supply air temperature hysteresis setpoint 1..8 2 K
Antifreeze XXX °C Antifreeze protection temperature limit −20..30 −5 °C
Hystersis anti XXX K Antifreeze protection hysteresis 1..8 2K
S Screen 2−1−2 Zone 2
Shown only when two−zone operation is set (Screen 6−1)
COOLING 2 POS: XXXXX Entry Default
Setpoint R2.8 XXX °C Supply air temperature setpoint −10..20 −3 °C
Hystersis R2.8 X K Supply air temperature hysteresis setpoint 1..8 2 K
