Menu structure UA 300 D Controller type UA 111 X
55
E 2007 − ECKELMANN | BERLINER STRASSE 161 | 65205 WIESBADEN | FON +49(0)611 7103-0 | FAX 49(0)611 7103-133 | eckelmann.de
Version 2.03 27. Juni 2008
S Screen 2−1−3 Zone 1A Altern.
Shown only when two−zone operation is set (Screen 6−1)
COOLING 1A POS: XXXXX Entry Default
Setpoint R2.x XXX °C Supply air temperature setpoint −10..20 −1 °C
Hystersis R2.x X K Supply air temperature hysteresis setpoint 1..8 2 K
Antifreeze XXX °C Antifreeze protection temperature limit −20..30 −4 °C
Hystersis anti XXX K Antifreeze protection hysteresis 1..8 2K
S Screen 2−1−4 Zone 2A Altern.
Shown only when two−zone operation is set (Screen 6−1) and setpoint toggle is not disabled (Screen 3−3)
COOLING 2A POS: XXXXX Entry Default
Setpoint R2.8 XXX °C Supply air temperature setpoint −10..20 −1 °C
Hystersis R2.8 X K Supply air temperature hysteresis setpoint 1..8 2 K
S Screen 2−2 Defrost
DEFROST POS: XXXXX
1 Zone 1 Continue to Screen 2−2−1
2 Zone 2 Continue to Screen 2−2−2; shown only when two−zone operation is set (Screen 6−1)
3 Zone 1A Altern. Continue to Screen 2−2−3; shown only when setpoint toggle is enabled (Screen 3−3)
4 Zone 2A Altern. Continue to Screen 2−2−4; shown only when two−zone operation is set (Screen 6−1) and only
when setpoint toggle is enabled (Screen 3−3)
S Screen 2−2−1 Zone 1
DEFROST 1 POS: XXXXX Entry Default
Def. End. Tmp. XX °C Defrost termination temperature setpoint −−, 5..20 8 °C
S Screen 2−2−2 Zone 2
DEFROST 2 POS: XXXXX Entry Default
Def. End. Tmp. XX °C Defrost termination temperature setpoint −−, 5..20 5 °C
