Menu structure UA 300 D Controller type UR 141
90
Version 2.03 27. Juni 2008
7.3.5 Menu 4 Messages
MESSAGES POS: XXXXX
1 View Continue to Screen 4−1 Show message log
2 Acknowledge Messages in message log are cancelled; alarms are cancelled after being shown: press
ESC to go back
3 Delete Continue to Screen 4−3
S Screen 4−1 View messages
MESSAGES POS: XXXXX
Error Message 1: Fault 1 message text
dd.mm.yy hh:mm ON Start of Fault 1
dd.mm.yy hh:mm OFF End of Fault 1 (only when Fault 1 terminated)
...
Error Message n: Fault n message text
dd.mm.yy hh:mm ON Start of Fault n
dd.mm.yy hh:mm OFF End of Fault n (only when Fault n terminated)
S Screen 4−2 Acknowlegde messages
Alarms Cancelled! is displayed.
S Screen 4−3 Delete messages
MESSAGES POS: XXXXX Entry
Delete !
Are you sure ?
NO: ESC YES: ↵
Safety prompt for deleting messages;
press ESC to go back after cancelling messages
↵, ESC
7.3.6 Menu 5 Archive
ARCHIVE POS: XXXXX
dd.mm.yy hh:mm Time of archiving Record 1
Zone 1: abcdef x °C Status and temperature of Zone 1, see Note *)
Zone 2: abcdef x °C Status and temperature of Zone 2, see Note *); shown only when two−zone operation is set
(Screen 6−1)
...
dd.mm.yy hh:mm Time of archiving Record n
Zone 1: abcdef x °C Status and temperature of Zone 1, see Note *)
Zone 2: abcdef x °C Status and temperature of Zone 2, see Note *); shown only when two−zone operation is set
(Screen 6−1)
