Menu structure UA 300 D Controller type UA 111 X
53
E 2007 − ECKELMANN | BERLINER STRASSE 161 | 65205 WIESBADEN | FON +49(0)611 7103-0 | FAX 49(0)611 7103-133 | eckelmann.de
Version 2.03 27. Juni 2008
S Screen 1−5 Alarm
ALARM POS:XXXXX
Alarm Relay XXX Current ON/OFF status of alarm output Terminal 15/16/18
Hi Temp Setp.1 XX °C High temperature setpoint Zone 1
Lo Temp Setp.1 XX K Low temperature setpoint Zone 1
Hi Temp Setp.2 XX °C High temperature setpoint Zone 2; shown only when two−zone operation is set
(Screen 6−1)
Lo Temp Setp.2 XX K Low temperature setpoint Zone 2; shown only when two−zone operation is set
(Screen 6−1)
S Screen 1−6 Compressor
COMPRESSOR POS:XXXXX
Compressor 1 XXX Current ON/OFF status of Compressor 1 output Terminals 43/44
Compressor 2 XXX Current ON/OFF status of Compressor 2 output Terminals 53/54
S Screen 1−7 Cooling Zone 2
COOLING 2 POS:XXXXX
Cooling XXX Current ON/OFF status of cooling Zone 2 Terminals35/36/38
Run Time XX % Cooling relay on time during last day (00:00 − 24:00 hours)
Starts X Cooling relay actuations during last day
Setpoint R2.8 XXX °C Supply air temperature setpoint for comparison
Hystersis R2.8 XXX K Supply air temperature hysteresis setpoint
S Screen 1−8 Defrost Zone 2
DEFROST 2 POS:XXXXX
Defrost 2 XXX Current ON/OFF status of defrosting Zone 2
Def. End. Tmp. XXX °C Defrost termination temperature for comparison
Last DefrstWe XX hh:mm Day and time of last defrost cycle started
