Menu structure UA 300 D Controller type UR 141
82
Version 2.03 27. Juni 2008
S Screen 1−2 Cooling Zone 1
COOLING 1 POS: XXXXX
Cooling XXX Current ON/OFF status of cooling Zone 1 Terminals 25/26/28
Run Time XX % Cooling relay on time during last day (00:00 − 24:00 hours)
Starts X Cooling relay actuations during last day
Temp. R4.2 XXX °C Current room air sensor R 4.1 setpoint for comparison
Setpoint R4.1 XXX °C Room air sensor R 4.1 setpoint
Hystersis R4.1 XXX K Room air sensor R 4.1 hysteresis
S Screen 1−3 Defrost Zone 1
DEFROST 1 POS: XXXXX
Counting Rate X Counting rate
Defrost Counter X Defrost counter
Defrost 1 XXX Current ON/OFF status of defrosting Zone 1 Terminals 43/44
Temp. R1.1 XXX °C Current temperature on evaporator sensor R1.1
Temp. R1.2 XXX °C Current temperature on evaporator sensor R1.2
Def. End. Tmp. XXX °C Defrost termination temperature for comparison
Wait Time XX m Waiting time setpoint
Drip Time XX m Drip time setpoint
Last DefrstWe XX hh:mm Day and time of last defrost cycle started
S Screen 1−4 Fans Zone 1
FANS 1 POS: XXXXX
Fans XXX Current ON/OFF status of fan Zone 1 Terminals 63/64
Temp. R1.1 XXX °C Current temperature on evaporator sensor R1.1
Fan Delay XX °C Fan delay
S Screen 1−5 Alarm
ALARM POS: XXXXX
Alarm Relay XXX Current ON/OFF status of alarm output Terminal 15/16/18
Hi Temp Setp.1 XX °C High temperature setpoint Zone 1
Lo Temp Setp.1 XX K Low temperature setpoint Zone 1
Hi Temp Setp.2 XX °C High temperature setpoint Zone 2; shown only when two−zone operation is set (Screen 6−1)
Lo Temp Setp.2 XX K Low temperature setpoint Zone 2; shown only when two−zone operation is set (Screen 6−1)
