Menu structure UA 300 D Controller type UR 141
92
Version 2.03 27. Juni 2008
A meaningful name that describes the refrigeration point in more detail should be entered, e.g.
Cheese Counter 2 and CC2. The name is entered in the screens of the CI 3000 Store Computer or
AL 300 Operator Terminal. Direct entry cannot be made in the UA 300 D screens displayed on ope-
rator terminals. The name also cannot be entered with the BT 300 x Operator Interface.
S Screen 6−2 Controller
CONTROLLER POS: XXXXX
1 Type and Version Continue to Screen 6−2−1
2 Temp. Display Continue to Screen 6−2−2
3 Alarm Delay Continue to Screen 6−2−3
4 230V Inputs Continue to Screen 6−2−4
5 Sensor Type Continue to Screen 6−2−5
S Screen 6−2−1 Type and Version
VERSION POS: XXXXX Entry Default
Ctrlr. Type XXXXXXX Set by DIP switch S3 UR141
Software Vers.: XXXX Software version of case/coldroom controller (EPROM)
Serial No.: XXXXXX Device No. of case/coldroom controller
(from EEPROM)
S Screen 6−2−2 Temp. Display
DISPLAY POS: XXXXX Entry Default
Offset XX K Offset for temperature display −10..10 0K
S Screen 6−2−3 Alarm Delay
ALARMDELAY POS: XXXXX Entry Default
Sensor Fault XX m Sensor break alarm delay 0..30 15 min
High/Low Temp. XX m High/low temperature alarm delay 0..150 60 min
Door Open XX m Door open alarm delay 0..60 15 m
No Defrost XX h No defrost alarm delay −−, 2..168 48 h
Selfholding X Alarm self−hold with manual alarm cancellation (YES) or
automatic cancellation on send (NO)
, ,
(Y/N)
N
