Menu structure UA 300 D Controller type UR 141
93
E 2007 − ECKELMANN | BERLINER STRASSE 161 | 65205 WIESBADEN | FON +49(0)611 7103-0 | FAX 49(0)611 7103-133 | eckelmann.de
Version 2.03 27. Juni 2008
S Screen 6−2−4 230V Inputs
Only trained personnel should be allowed to change inputs, as changes may affect other functions.
230V INPUT POS: XXXXX Entry Default
Input1:Door1 Function of Digital Input 1 D11/D12 −
Coldroom door 1 (closed/open)
− Door1
Input2:SETP.TOG. Function of Digital Input 2 D21/D22 −
Setpoint toggle
− SETP.TOG.
Input3:Door2 Function of Digital Input 3 D31/D32 −
Coldroom door 2 (closed/open)
− Door 2
S Screen 6−2−5 Sensor Type
Entry chooses between values. Checkmark indicates current setting.
SENSORS POS: XXXXX Entry Default
L243 √ Temperature range −50 .. 50°C
Sensor type L243 is identical with K243
↵ √
K277 Temperature range −50 .. 50°C ↵
5K3A1 Temperature range 0 .. 100°C ↵
S Screen 6−3 Cooling
COOLING POS: XXXXX Entry Default
Cont Cool Mon. XX m Duration of forced interruption of cooling in continuous
running
−−, 0..15 0 min
Emergency Op. XX % In failure of required sensors, the solenoid is actuated
to adjust to the set opening in %
0..100 10%
S Screen 6−4 Language
LANGUAGE POS: XXXXX Entry Default
Deutsch D √ ↵ √
English GB ↵
Francais F ↵
Cesky CZ ↵
