Menu structure UA 300 D Controller type UA 111 X
57
E 2007 − ECKELMANN | BERLINER STRASSE 161 | 65205 WIESBADEN | FON +49(0)611 7103-0 | FAX 49(0)611 7103-133 | eckelmann.de
Version 2.03 27. Juni 2008
S Screen 2−4−4 Zone 2A Altern.
ALARM 2A POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High Temperature
alarm is generated
−30..30 8 °C
Low Temp Setp. XX K Low temperature setpoint (difference below temperature
control setpoint) at which Low Temperature alarm is gene-
rated
−−, 0..6 2 K
S Screen 2−5 Compressor
COMPRESSOR POS: XXXXX
1 Setpoints Continue to Screen 2−5−1, Setpoints
2 Setpoint toggle Continue to Screen 2−5−2, Setpoint Toggle
S Screen 2−5−1 Setpoints (Compressor)
COMPRESSOR POS: XXXXX Entry Default
Enable C1 XXX Enable Compressor 1 ↑, ↓,
(ON/OFF)
ON
Enable C2 xxx Enable Compressor 2 ↑, ↓,
(ON/OFF)
ON
Delay C1 ON xxx s Start delay Compressor 1 0..250 60s
Delay C2 ON xxx s Start delay Compressor 2 0..250 180s
Delay C1 OFF xxx s Stop delay Compressor 1 0..250 60s
Delay C2 OFF xxx s Stop delay Compressor 2 0..250 15s
S Screen 2−5−2 Setpoint toggle (Compressor)
Compr. alt. POS: XXXXX Entry Default
Delay C1 ON xxx s Start delay Compressor 1 0..250 120s
Delay C2 ON xxx s Start delay Compressor 2 0..250 240s
Delay C1 OFF xxx s Stop delay Compressor 1 0..250 75s
Delay C2 OFF xxx s Stop delay Compressor 2 0..250 15s
