Menu structure UA 300 D Controller type UA 111 X
62
Version 2.03 27. Juni 2008
S Screen 6−2−2 Temp. Display
DISPLAY POS: XXXXX Entry Default
Offset XX K Offset for temperature display −10..10 0K
S Screen 6−2−3 Alarm Delay
ALARMDELAY POS: XXXXX Entry Default
Sensor Fault XX m Sensor break alarm delay 0..30 15 min
High/Low Temp. XX m High/low temperature alarm delay 0..120 60 min
No Defrost XX h No defrost alarm delay −−, 2..168 24 h
Selfholding X Alarm self−hold with manual alarm cancellation (YES) or
automatic cancellation on send (NO)
↑, ↓,
(Y/N)
N
S Screen 6−2−4 230V Inputs
Only trained personnel should be allowed to change inputs, as changes may affect other functions.
230V INPUT POS: XXXXX Entry Default
Input1:STORE LIGHT Function of Digital Input 1 D11/D12 −
Store lighting (2/3)
− STORE LIGHT
Input2:SETP.TOG. Function of Digital Input 2 D21/D22 −
Setpoint toggle
− SETP.TOG.
Input3:LIGHT SWITCH Function of Digital Input 3 D31/D32 −
Lighting switch (manual case switch)
− LIGHT SWITCH
S Screen 6−2−5 Sensor Type
Entry chooses between values. Checkmark indicates current setting.
SENSORS POS: XXXXX Entry Default
L243 √ Temperature range −50 to 50°C
Sensor type L243 is identical with K243
↵ √
K277 Temperature range −50 to 50°C ↵
5K3A1 Temperature range −50 .. 100°C ↵
S Screen 6−3 Cooling
COOLING POS: XXXXX Entry Default
Cont Cool Mon. XX m Duration of forced interruption of cooling in continuous
running
−−, 0..15 0 min
Emergency Op. XX % In failure of required sensors, the solenoid is actuated to
adjust to the set opening in %
0..100 40%
