Menu structure UA 300 D Controller type UA 111 XP
76
Version 2.03 27. Juni 2008
S Screen 6−1 Refrger. Point
REFR. PT. POS: XXXXX Entry Default
Refrger. Point Name: Text only
xxxxxxxxxxxxxxx Free text entry describing refrigeration point (see note follo-
wing table)
Case/coldrm.
controller
Item ID: XXXXX Free text entry displayed in screens after POS: (see note
following table)
UA300
Priority: XX Alarm priority in failure of refrigeration point or when global
controller priority is set (Screen 6−5)
↑, ↓,
or numbers
(0..99)
1
Refr. Sys. No.: XX No. of pack controller allocated to case/coldroom controller ↑, ↓,
or numbers
(−−, 1..9)
1
Refr. Sys. Type: XXX Associated compressor pack.
Parameter only required when linked to a VS 3000 BS
having several zones. If a different type of pack controller
is used, set this parameter blank (−−−)
↑, ↓,
or numbers
(−−−, Z1, Z2)
−−−
No. Sensors XX Number of temperature sensors connected. After entering
o sensor scan is performed to redetermine the number of
sensors.
↵
Temp. Zones X Number of temperature zones:
Single−zone operation/
Two−zone operation
↑, ↓,
or numbers
(1, 2)
2
A meaningful name that describes the refrigeration point in more detail should be entered, e.g.
Cheese Counter 2 and CC2. The name is entered in the screens of the CI 3000 Store Computer or
AL 300 Operator Terminal. Direct entry cannot be made in the UA 300 D screens displayed on ope-
rator terminals. The name also cannot be entered with the BT 300 x Operator Interface.
S Screen 6−2 Controller
CONTROLLER POS: XXXXX Entry
1 Type and Version Continue to Screen 6−2−1 1
2 Temp. Display Continue to Screen 6−2−2 2
3 Alarm Delay Continue to Screen 6−2−3 3
4 230V Inputs Continue to Screen 6−2−4 4
5 Sensor Type Continue to Screen 6−2−5 5
S Screen 6−2−1 Type and Version
VERSION POS: XXXXX Entry Default
Ctrlr. Type XXXXXXX Set by DIP switch S3 − UA111XP
Software Vers.: XXXX Software version of case/coldroom controller (EPROM) −
Serial No.: XXXXXX Device No. of case/coldroom controller
(from EEPROM)
−
