Menu Structure of VS 3000
99
eckelmann.de
E 2007 - ECKELMANN AG | BERLINER STRASSE 161 | 65205 WIESBADEN | TELEFON + 49(0)611 71 03-0 | FAX +49(0)611 71 03-133
S Menu 3-2-1-4 LP-control night
LP CONT N POS: XXXXX Entry
Default / Dimension
NT LT Dim.
to-max. XXX °C Max. t
0
- setpoint for setpoint shift -50..10 -6 -34 °C
tr-min. XXX °C min room temperature for setpoint shift
(Only shown when t
0
shift by room temperature is
selected in Screen 3-2-1-2-a)
-25..20 15 15 °C
to-min. XXX °C min t
0
setpoint for setpoint shift -50..1 0 -10 -38 °C
tr-max. XXX °C Max. room temperature for setpoint shift
(Only shown when t
0
shift by room temperature is
selected in Screen 3-2-1-2-a)
-18..35 25 25 °C
humid adapt. X Humidity shift activated YES/NO ↑, ↓,(Y/N) N N -
Basic load time ON → Show basic times t
b
ON → Screen 3-2-1-4-a
Vari. load time ON → Show variable times t
v
ON → Screen 3-2-1-4-b
Basic unload time OFF → Show basic times t
b
OFFS → Screen 3-2-1-4c
Vari. unload time OFF → Show variable times t
v
OFF → Screen 3-2-1-4-d
Dead band XX K Switching hysteresis 1..10 4 4 K
Control const. XX K Max. control error for variable control times 1..15 10 8 K
S Masque 3-2-1-4-a Basic load time
B. LOAD T POS: XXXXX Entry
Default / Dimension
NT LT Dim.
BasLoadTC1 XXXs 0..250 60 60 sec
BasLoadTC2 XXXs
O
n
l
y
t
h
e
a
v
a
i
l
a
b
l
e
c
a
p
a
c
i
t
y
s
t
a
g
e
s
a
r
e
s
h
o
w
n
3..250 140 140 sec
BasLoadTC3 XXXs
Onl
y
the available capacit
y
stages are shown
3..250 200 200 sec
BasLoadTC4 XXXs 3..250 250 250 sec
...
O
n
l
y
t
h
e
a
v
a
i
l
a
b
l
e
c
a
p
a
c
i
t
y
s
t
a
g
e
s
a
r
e
s
h
o
w
n
BasLoadTC12 XXXs
Onl
y
the available capacit
y
stages are shown
3..250 250 250 sec
VS 3000 basic module: Capacity stage 1 - max. 4
With 1st SIOX extension module: Capacity stage 1 - max. 8
With 2nd SIOX extension module: Capacity stage 1 - max. 12
