ECKELMANN VS 3000 User Manual

Version 2.02 15.05.2007
Menu Structure of VS 3000
109
eckelmann.de
E 2007 - ECKELMANN AG | BERLINER STRASSE 161 | 65205 WIESBADEN | TELEFON + 49(0)611 71 03-0 | FAX +49(0)611 71 03-133
S Masque 3-8-c Def.timer Z2R
DEF.Z2R POS: XXXXX Entry
Default / Dimension
NT LT Dim.
Defr. 1 XXXXX hh.mm Defrost timer for Z2 coldrooms with auxiliary and
separate defrosting.
(Only shown when Auxiliary Defrost or Separate is
selected in Screen 3-8-a)
↑, ↓
Mo-Su
Mo-Fr
Mo-Sa
Sa-Su
-----
Mo,Tu,We,Th,
Fr,Sa, Su,
number
----- ----- -
...
Defr. 7 XXXXX hh.mm Defrost timer for Z2 coldrooms with auxiliary and
separate defrosting.
(Only shown when Auxiliary Defrost or Separate is
selected in Screen 3-8-a)
↑, ↓
Mo-Su
Mo-Fr
Mo-Sa
Sa-Su
-----
Mo,Tu,We,Th,
Fr,Sa, Su,
number
----- ----- -
8.1.5 Menu 4 Clock
CLOCK POS: XXXXX Entry
Default / Dimension
NT LT Dim.
Setpoint toggle
XXX
Setpoint toggle external or via internal clock (INT
or EXT)
↑, ↓
(INT/EXT)
EXT EXT -
Current time → Show current date / time → Screen 4-a
Toggle time → Entry screen for toggle times
(Only shown when setpoint toggle is set to INT)
→ Screen 4-b
S Masque 4-a Current time
CLOCK POS: XXXXX Entry
Default / Dimension
NT LT Dim.
Date: xxdd.mm.yy Current day, date Number Date Date -
Time: hh.mm Current time Number Time Time -
Auto daylt. savg X Automatically adjust clock for daylight saving
changes (YES/NO)
↑, ↓
(Y/N)
Y Y -
