Version 2.02 15.05.2007
Menu Structure of VS 3000
105
eckelmann.de
E 2007 - ECKELMANN AG | BERLINER STRASSE 161 | 65205 WIESBADEN | TELEFON + 49(0)611 71 03-0 | FAX +49(0)611 71 03-133
S Menu 3-4 Liq.level monitor
REFR. MON POS: XXXXX Entry
Default / Dimension
NT LT Dim.
Dellow level XXX m Delay for Low Refrigerant Level alarm -, 1..120 60 60 min
S Menu 3-5 Ext. alarms
Ext. ALARM POS: XXXXX Entry
Default / Dimension
NT LT Dim.
Time delay XXX s Delay in seconds for External Alarm report 3..250 5 5 sec
Alarm message:
XXXXXXXXXXXX.XXX.XXX.X
Message displayed in occurrence of external
alarms.
Default text: External Alarm or Speed contr.
Tex t
S Menu 3-6 Base load
BASE LOAD POS: XXXXX Entry
Default / Dimension
NT LT Dim.
Cycle time C. XXX m Cycle time for compressor base load rotation 5..720 45 45 min
BaseLoadRot.F Y/N Activate base load rotation for fans
(Only shown when Step Controller is selected as
HP control type in Screen 3-3-1-a)
↑, ↓,(Y/N) N N -
On time cond. Y/N Prompt for run time equalization
(Only shown when Fan Rotation is set to Y)
↑, ↓,(Y/N) N N -
Cycle time F. XXX m Cycle time for fan base load rotation
(Only shown when Fan Rotation is set to Y)
5..720 720 720 min
S Menu 3-7 Messages
Messages POS: XXXXX Entry
Default / Dimension
NT LT Dim.
Mot. cutout C X Compressor motor overload cutout compressor
tripped
-, 0..2 2 2 -
Mot. cutout F X Fan motor overload cutout tripped -, 0..2 2 2 -
Oil diff.pr. X Compressor low oil pressure cutout/HP cutout trip-
ped
-, 0..2 2 2 -
Cyl. temp. X Cylinder head temperature limit exceeded -, 0..2 2 2 -
HP cutout X High-pressure cutout tripped - , 0..2 1 1 -
LP cutout X Low-pressure cutout tripped -, 0..2 2 2 -
Low LP X Low pressure limit to exceeded -, 0..2 2 2 -
High HP X High pressure limit tc exceeded -, 0..2 2 2 -
Meas.err.cyl. X Cylinder head temperature measuring loop error -, 0..2 2 2 -
Meas. error HP X High-pressure measuring loop error -, 0..2 2 2 -
Meas. error LP X Low-pressure measuring loop error -, 0..2 1 1 -
