ECKELMANN VS 3000 User Manual

Version 2.02 15.05.2007
Menu Structure of VS 3000
101
eckelmann.de
E 2007 - ECKELMANN AG | BERLINER STRASSE 161 | 65205 WIESBADEN | TELEFON + 49(0)611 71 03-0 | FAX +49(0)611 71 03-133
S Menu 3-2-2 HD-Control
HD CONT POS: XXXXX
1 Control Move to Menu 3-2-2-1
2 Setpoints Move to Menu 3-2-2-2
S Menu 3-2-2-1 HD-Control
HP CONT POS: XXXXX Entry
Default / Dimension
NT LT Dim.
Control type → Election list for HP control type → Screen 3-3-1-a
min speed XXX% min fan speed
(Only shown when speed controller is selected as
control type in Screen 3-3-1-a)
0..50 0 0 %
p-factor XX P factor (amplification factor) for fan speed control
signal (only shown when control type selected as
Speed Controller or Combined Controller - Screen
3-2-2-1-a)
0.1to2.0 1.0 1.0 V/°C
i-factor XX I factor (integral factor) for fan speed control signal
(only shown when control type selected as Speed
Controller or Combined Controller - Screen
3-2-2-1-a)
0.00 to 1.00 0.20 0.20 V/
°C*s
Timeb.I-fact. XX Time interval for calculating I-part for fan speed
con-trol signal (only shown when control type se-
lected as Speed Controller or Combined Controller
- Screen 3-2-2-1-a)
1to60 3 3 s
Switch mode XXv Actuation type fan control/star-delta mode (only
shown when control type selected as Step Control-
ler - Screen 3-2-2-1-a)
→ Screen 3-2-2-1-b
Fast speed N XX High speed (delta mode) also with night setpoint
allowed Y/N (only shown when control type selec-
ted as Speed Controller (Screen 3-2-2-1-a) and
actuation type selected as SSFF or SSSF (Screen
3-2-2-1-b)
↑, ↓,(Y/N) Y Y -
Del. slow speed. XX Delay for loading fan stage in star mode after
being unloaded in delta mode(only shown when
control type selected as Speed Controller (Screen
3-2-2-1-a) and actuation type selected as SSFF or
SSSF (Screen 3-2-2-1-b)
0to30 5 → s
tc-max. XX°C Maximum t
c
with continuous HP control
(Only shown when speed controller is selected as
control type in Screen 3-3-1-a)
25..56 40 40 °C
Fan off w/comp X Stop fan with compressor YES/NO ↑, ↓,(Y/N) N N -
Fan off by al. X Stop fan on actuation of motor overload cutout Y/N ↑, ↓,(Y/N) Y Y -
