Version 2.02 15.05.2007
Specifications of VS 3000
119
eckelmann.de
E 2007 - ECKELMANN AG | BERLINER STRASSE 161 | 65205 WIESBADEN | TELEFON +49(0)611 71 03-0 | FAX +49(0)611 71 03-133
10.1 Electrical Data of VS 3000
VS 3000
Power supply U
Nom
= 230 V AC, 200 - 265 V AC, 50/60 Hz
Rated power 6W
Leakage current over PE max. 1 mA
Relay outputs 10 x 250 V AC, 6 A (6 N.O., 4 changeover), floating
Transverse voltage between outputs max. 400 V AC
Digital inputs 23 x 230 V AC floating
Transverse voltage between inputs max. 400 V AC
Analog inputs 12 x PT1000 temperature sensors, 2-wire type
2 x PT1000 temperature sensors, 4-wire type
2 x pressure sensors 4..20 mA and
1 x humidity sensor 4..20 mA
all inputs internally convertible by jumper
(Leads running to analog inputs must be shielded.)
Analog outputs 2 x 0-10 V / 4-20 mA (internally convertible by jumper)
0-10 V (min. load 1 k )/4-20 mA (max. load 800Ω)
(Leads running to analog inputs must be shielded.)
Fieldbus port CAN bus, floating
Data ports Serial RS232 / RS485
Data port for SIOX
TTY (passive)
Other ports Power supply for external SIOX modules
Archive memory Compressor run times, starts, activity, fault reports
Monitoring function Watchdog
Real-time clock Byttery-backed
Lithium cell (Typ CRC 2450 N / 3V Lithium,
(10 years shelf life), typically 12 min/yr at 25°C
Temperature range Transport: -20 .. 80°C
Operation: 0 .. 50°C
Temperature change Transport: max. 20 K/h
Operation: max. 10 K/h
Relative humidity
(non-condensing)
Transport: 8% .. 80%
Operation: 20% .. 80%
Shock to DIN EN
60068-2-27
Transport and operation: 30 g
Vibration 10-150 Hz
to DIN EN 60082-2-6
Transport and operation: 2 g
Atmospheric pressure Transport: 660 hPa .. 1060 hPa
Operation: 860 hPa .. 1060 hPa
Enclosure IP20
CE conformity Conforming to EC Directives
73/23/EEC (Low-Voltage Directive)
89/336/EEC (EMC Directive)
10 Specifications of VS 3000
