ECKELMANN VS 3000 User Manual

Version 2.02 15.05.2007
Pin and Terminal Assignments of VS 3000
75
eckelmann.de
E 2007 - ECKELMANN AG | BERLINER STRASSE 161 | 65205 WIESBADEN | TELEFON +49(0)611 71 03-0 | FAX +49(0)611 71 03-133
5.5 Inputs/outputs of SIOX D2D extension module for discharge gas defrosting
Digital Intputs
Function SIOX D2D
Manual defrost Z2 cases 50, 51
Manual defrost Z2 coldrooms 52, 53
Disable defrost Z2 cases 56, 57
Disable defrost Z2 coldrooms 58, 59
HP cutout Z2 cases 62,63
HP cutout Z2 coldrooms 64, 65
Reserved 54, 55
Reserved 66, 67
Reserved 60, 61
Reserved 68, 69
Reserved 70, 71
Reserved 72, 73
Digital Outputs
Function SIOX D2D
Discharge gas feed solenoid valve Z2 cases 13, 14
Discharge gas feed solenoid valve Z2 coldrooms 23, 24
Reserved 33, 34
Drain heater Z2 coldrooms 43, 44
Suction line solenoid valve Z2 cases 15, 16, 18
Suction line solenoid valve Z2 coldrooms 25, 26, 28
Reserved 35, 36, 38
Discharge line solenoid valve 45, 46, 48
Interfaces
Function SIOX D2D
External SIOX connection input SIOX IN
External SIOX connection output SIOX OUT
Power Supply
Function SIOX D2D
SIOX power supply
0V
9V
0V
24 V
Shield
91
92
93
94
95
