ECKELMANN VS 3000 - S Menu 3-2-2-2 Setpoints

Version 2.02 15.05.2007 Menu Structure of VS 3000
102
S Masque 3-2-2-1-a Control type
CONTROL POS: XXXXX Entry
Default / Dimension
NT LT Dim.
Step controller √ Selection list for HP control type √ √ √ -
Speed controller √
Combi cont. paral √
Combi controller √
S Masque 3-2-2-1-b HP Actuation Type - Star/Delta Operating Mode
Switch mode POS: XXXXX Entry
Default / Dimension
NT LT Dim.
Direct √ Load and unload fan stages in sequence - stan-
dard operating mode. Star-delta mode deactivated.
√ √ √ -
SSFF Star-delta operating mode: Fans start successively
at low speed (S) and then successively switch to
high speed (H)
√
SSSF Star-delta operating mode: Fans start successively
at low speed (S) and then switch simultaneously to
high speed (H)
√
S Menu 3-2-2-2 Setpoints
HP CONT POS: XXXXX Entry
Default / Dimension
NT LT Dim.
tc-min XX°C min tc setpoint for setpoint shift -10..35 25 25 °C
ta-min XX°C min outdoor temperature for setpoint shift 0..15 15 15 °C
tc-max XX°C Max. tc setpoint for setpoint shift -10..45 25 25 °C
ta-max XX°C Max. outdoor temperature for setpoint shift 16..45 30 30 °C
tc Offset N XX K tc offset in night operation 0..15 0 0 K
Ht. rec. mode X Activate/deactivate HR mode ↑, ↓,(Y/N) N N -
Run Time HRC h Maximum compressor run time in HR mode 0..10 -- -- h
Off Time HRC XX m Compressor standstill time when disabled by max.
run time monitoring on disabling
30..180 60 60 min
HR max. XX°C tc-Setp in heat recovery mode -10..50 46 46 °C
HR dif. XX K Switching hysteresis in heat recovery mode 1..10 4 4 K
Bas. load time F ON → Set basic times tb ON → Screen 3-2-2-2-a
Var. load time F ON → Set variable times tv ON → Screen 3-2-2-2-b
Bas.unload time F OFF → Set basic times tb OFF → Screen 3-2-2-2-c
Var.unload time F OFF → Set variable times tv OFF → Screen 3-2-2-2-d
Dead band XX K Switching hysteresis 1..20 6 6 K
Control const XX K Max. control error for variable control times 1..10 10 10 K
