ECKELMANN VS 3000 User Manual

Version 2.02 15.05.2007 Menu Structure of VS 3000
104
S Masque 3-2-2-2-d Var.unload time F OFF
V. UNLO T POS: XXXXX Entry
Default / Dimension
NT LT Dim.
V. unlo t. F 1 XXX s 3..250 20 20 sec
V. unlo t. F 2 XXX s
O
n
l
y
t
h
e
a
v
a
i
l
a
b
l
e
c
a
p
a
c
i
t
y
s
t
a
g
e
s
a
r
e
s
h
o
w
n
3..250 40 40 sec
V. unlo t. F 3 XXX s
Onl
y
the available capacit
y
stages are shown
3..250 60 60 sec
V. unlo t. F 4 XXX s 3..250 90 90 sec
...
O
n
l
y
t
h
e
a
v
a
i
l
a
b
l
e
c
a
p
a
c
i
t
y
s
t
a
g
e
s
a
r
e
s
h
o
w
n
V. unlo t. F 12 XXX s
Onl
y
the available capacit
y
stages are shown
3..250 90 90 sec
VS 3000 basic module: Condenser capacity stages 1 - max. 4
With 1st SIOX extension module: Condenser capacity stages 1 - max. 8
With 2nd SIOX extension module: Condenser capacity stages 1 - max. 12
S Menu 3-3 Comp. monitor
COMP MON POS: XXXXX Entry
Default / Dimension
NT LT Dim.
Comp. OFF temp XXX °C Disable one compressor at high temperature 80..180 120 120 °C
Comp. ON temp XXX °C Enable compressor after high temperature 50..120 100 100 °C
Comp temp del. XX m Delay for High Cylinder Head Temperature Cx
alarm
0..5 3 3 min
Inj.Temp XXX °C Temperature threshold to activate interstage feed 80..110 - - °C
Inj.Temp.HR XXX °C Temperature threshold to activate interstage feed
in HR mode
90..140 - - °C
Dif.Inj.Temp XXX K THysteresis to deactivate interstage feed 5..15 10 10 K
tc Comp OFF XXX °C t
c
limit for disabling compressor capacity stages -10..56 52 52 °C
tc Comp ON XXX °C t
c
limit for enabling compressor capacity stages
after disabling
-10..50 42 42 °C
NT-Cascade 1 XXX CAN bus Node No. NT Pack 1(L T CO2 systems) 1..9,-- -- -- -
NT-Cascade 2 XXX CAN bus Node No. NT Pack 2(L T CO2 systems) 1..9,-- - -- -
to Comp OFF XXX °C t
0
limit for compressor disable -50..2 -25 -46 °C
Del. to OFF XXX m Delay for Low LP alarm 0..60 10 10 min
Del. tc/HD OFF XXX m Delay for High tc/HP alarm 0..60 1 5 min
Min to diff. XXX K Minimum allowed difference between to and tc 5..15,-- -- -- K
Starts/h XXX Compressor starts per hour 4..16 6 6 -
Off Time S1. XXX s Minimum allowed difference between to and tc 0..250 40 40 s
Min. Superheat XX K Minimum allowed difference between to and tc 5..15 7 7 K
averaging toh. XX Minimum allowed difference between to and tc 1..50 5 5 -
