ECKELMANN VS 3000 User Manual

Version 2.02 15.05.2007
Menu Structure of VS 3000
107
eckelmann.de
E 2007 - ECKELMANN AG | BERLINER STRASSE 161 | 65205 WIESBADEN | TELEFON + 49(0)611 71 03-0 | FAX +49(0)611 71 03-133
Messages POS: XXXXX Entry Default / Dimension
NT LT Dim.
Speed ctrl. HP X HP speed adjuster fault with HP combined control-
ler
-, 0..2 2 2 -
M.err.Suct.temp X Suction gas temperature sensor measuring loop
error
-, 0..2 - - -
Low Superheat X Low suction gas superheat -, 0..2 2 2 -
S Menu 3-8 D2D (Discharge Gas Defrosting)
D2D POS: XXXXX Entry
Default / Dimension
NT LT Dim.
Def. Z2R → Defrost method Z2 coldrooms → Screen 3-9-a
Def.timer → Entry screen for defrost times → Screen 3-9-b
Def.timer Z2R → Entry screen for defrost times Z2R with separate
defrosting
(Only shown when Auxiliary Defrost or Separate is
selected in Screen 3-9-a)
→ Screen 3-9-c
tc Comp OFF XX°C Z1 capacity stages unloaded above specified tem-
peratures
30..40 35 35 °C
tc comp. OFF XX°C No Z1 capacity stages loaded above specified
temperatures
20..30 25 25 °C
Drain htr. Z2 XXm S tart delay for drain heating Z2 coldrooms 5..30 15 15 min
Defrost Z2 XXm Defrost duration Z2 cases 10..3 0 12 12 min
Comp. OFF Z2 X Disable Z2 compressors during defrosting YES/
NO
↑, ↓,(Y/N) Y Y -
Del.SuctL.Z2 XXXs Suction line open delay on termination of Z2 defros 10..100 30 30 S
C.Suct.1.on Z2 XX°C Z2 compressors remain disabled after Z2
defrosting until temperature C.Suct.l.on Z2 is attai-
ned
-10..5 -5 -5 °C
Node Nr. Z1 XXX Node No. of Z1 pack controller 1..9 --- --- -
to-Setpt Z1 X°C t
0
setpoint Z1 during discharge gas defrosting with
joint defrosting Z2 and Z2R
-30..-5 -20 -20 °C
Bas.Load t. Z1 XXs Basic load time Z1 during Z2 defrost 5..200 20 20 sec
Bas.unlo t. Z1 XXs Basic unload time Z1 during Z2 defrost 5..100 10 10 sec
Defrost Z2R XXm Defrost duration Z2 coldrooms
(Only shown when Auxiliary Defrost or Separate is
selected in Screen 3-9-a)
10..30 10 10 min
Del.SuctL.Z2R Suction line open delay on termination of Z2R def-
rost (only shown when Auxiliary Defrost or Sepa-
rate se-lected under defrost method for Z2 col-
drooms - Screen 3-8-a)
10..100 30 30 s
ForcedCool.Z2R Setpoint decrease Z1 and forced cooling (Y/N) N N -
