Version 2.02 15.05.2007 Installation and Startup of VS 3000
52
Setting service mode
Coding Switch 5 of DIP Switch S1 5 defines service mode:
DIP Switch S1
Coding Switch 5
Switch position Service mode
ON
ON Service mode
12345 67
OFF Normal operating mode
Following an electric power failure, the system starts in service mode with default parameters for ser-
vice purposes. Changes to parameters are not permanently saved (power failure). Coding Switch 5 of
DIP Switch S1 may only be set ON to invoke service mode.
Service mode must always be deactivated for normal system operation (Coding Switch 5 of DIP
Switch S1 must be set OFF)!
Setting firmware update mode
Coding Switches 6 and 7 of DIP Switch S1 define firmware update mode:
DIP Switch S1
Coding Switches
6and7
Switch
position
Firmware update mode
ON
ON Normal operating mode
1234567
OFF Firmware update mode
Coding Switches 6 and 7 of DIP Switch S1 may only be set OFF for downloading firmware. At this
setting the controller awaits firmware update from a connected Service PC. Firmware update mode
must always be deactivated for normal system operation (Coding Switches 6 and 7 of DIP Switch S1
must be set ON)!
If a switch position is changed after startup, the basic parameters for the set temperature range will be
loaded the next time the controlled is started (power failure) and the controller w ill perform first s tart. In
view of the large number of parameters, the basic parameters can also be loaded with the operating
terminal (see Section 8 - Menu Structure).
