ECKELMANN VS 3000 User Manual

Version 2.02 15.05.2007
Pin and Terminal Assignments of VS 3000
69
eckelmann.de
E 2007 - ECKELMANN AG | BERLINER STRASSE 161 | 65205 WIESBADEN | TELEFON +49(0)611 71 03-0 | FAX +49(0)611 71 03-133
Digital Outputs
Function Basic Module
Terminal No.
1. Extension Module
SIOX
Enable refrigeration points 1, 2 -
Toggle FC compressor 3, 4 -
Controller Compressor 1 13, 14 -
Controller Compressor 2 23, 24 -
Controller Compressor 3 33, 34 -
Controller Compressor 4 43, 44 -
Controller Compressor 5 - 13, 14
Controller Compressor 6 - 23, 24
Controller Compressor 7 - 33, 34
Controller Compressor 8 - 43, 44
Controller Condenser Fan 1 15,16, 18 -
Controller Condenser Fan 2 25, 26, 28 -
Controller Condenser Fan 3 35, 36, 38 -
Controller Condenser Fan 4 45, 46, 48 -
Controller Condenser Fan 5 - 15, 16, 18
Controller Condenser Fan 6 - 25, 26, 28
Controller Condenser Fan 7 - 35, 36, 38
Controller Condenser Fan 8 - 45, 46, 48
Analog Intputs
Function Basic Module
Terminal No.
1. Extension Module
SIOX
Outdoor temperature + Sensor
+ PT1000
- PT1000
- Sensor
1
2
3
4
-
-
-
-
Room temperature + Sensor
+ PT1000
- PT1000
- Sensor
5
6
7
8
-
-
-
-
Cylinder head temperature C1 +PT1000
- PT1000
9
10
-
-
Cylinder head temperature C2 11, 12 -
Cylinder head temperature C3 13, 14 -
Cylinder head temperature C4 15, 16 -
Cylinder head temperature C5 17, 18 -
Cylinder head temperature C6 19, 20 -
Cylinder head temperature C7 21, 22 -
Cylinder head temperature C8 23, 24 -
Low-pressure transducer + 24 V
4..20 mA
GND
35
36
37
-
-
-
High-pressure transducer + 24 V
4..20 mA
GND
44
45
46
-
Read FC output to deliver + 24 V
current or frequency 4..20 mA
GND
38
39
40
-
Humidity sensor (optional) + 24 V DC
4..20 mA
41
59
-
-
