MINUTEMAN 320
31
REV 13.1:2020
c. Head stock adaptors
d. Correct channel set installed
e. Threaded rod, bracket, and nuts
f. Telescoping or hard nose
g. Hardnose nose insert, if required
h. Bushing blocks or rollers
i. MAVD if equipped
5. Calculate bar feeder positioning
a. Consider lathe headstock stroke
b. Consider bar feeder reach capability
c. Determine distance based on manual specifications
d. Consider axial shift requirements
e. Verify collapsibility of telescoping nose
f. Verify Reach of telescoping nose
6. Install laser or string components for alignment and target to bar pusher
a. Lathe collet/chuck
b. Lathe guide bushing as required
c. Lathe spindle
i. Verify bar pusher reach and head stock stroke
ii. Verify axial shift reach and stroke
7. Drill and anchor bar feeder to floor
a. Verify floor is not heated
b. Drill holes complete through floor, entire 12 inch drill stroke
c. Drive anchors complete into floor with associated fender washers installed
d. Tighten anchors fully
8. Verify alignment, adjust as necessary
a. Verify bar pusher reach and head stock stroke
b. Verify axial shift reach and stroke
9. Install MAVD as required
a. Align MAVD
b. Adjust as required
10. Install telescoping or hard nose
a. Required inserts installed, as required
b. Align as required
c. Cut telescoping or hardnose nose, as required
