MINUTEMAN 320
41
REV 13.1:2020
Caution do not change the axial stoke distance once it has been set
by the installer.
The Position stop screws allow an axial stroke to be set to one of 3 positions. Once the bar
feeder has been installed changes to this screw position must not be changed. The position will
be determined by Edge Technologies to the lathe model.
Axial stop screw
location
