MINUTEMAN 320
80
REV 13.1:2020
5. Remove the upper access plate
Loosen retaining screws, do not remove
screws. The cover is slotted, remove AVD top
cover.
6. The center socket head cap screw
retaines the roller block. The 2 outer
socket head cap screws must stay in
position for roller block alingment.
DO NOT REMOVE
To Next Page
