STP-iXA3306 Series Turbomolecular Pump
MT-82E-001-H
Page 77
4
OPERATION
Table 27 shows the rated contacts for relays CR1 to CR8 in Figure 39.
Resistance Load (COS Ø=1)
Rated Load
30 V DC, 0.5 A
Rated Current
0.5 A
Maximum Contact Point Current
0.5 A
Maximum Open/Close Capacity
DC: 15 W
Minimum Applicable Load
10 mV DC, 10 μA
Table 27 - Rated contacts for relays CR1 to CR8
