Double-sided Printing
Document ID: OMM-00165 Rev. C Pro 32r Operations Guide 161
7.3.4 Blockout - Head-to-Tail - Print Side B
1. Load the printed media to the machine, and bring the slits to the front edge of the print table.
NOTE: Make sure that the media is properly loaded. If you detect a tilt, reload the media.
2.
Figure 7-28
Measure the media.
3. Open a job (Side B), and in the Job Settings dialog box, check Blockout option.
4. Make sure the job is centered.
• Make sure that the Side B printing starts with the last job printed on Side
A, and ends with
the first one.
• Make sure to print the same number of copies from each job.
5. Print Side B.
The media automatically advances, until the sensor detects the stripes and the
print start sat the correct position.
The media advances until the sensor detects the stripes on Side A, and the job is printed at the required location. The media
automatically advances, until the sensor detects the stripes and the print starts at the correct position.
In both Head-to-Head and Head-to-Tail processes, if the Blockout Sensor does not recognize the two stripes, Figure 7-29 appears.
If this happens you should carry out sensor calibration. (See Blockout Sensor Calibration.)
Figure 7-29
