Setting on the V820 control panel:
1
Input code number 3112!
2
Press the E key

Parameter 500 displayed.
3
Press the E key

Sir [o] displayed.
4
Press the >> key

Parameter 290 FAm 05 appears.
(Functional cycle cutting
processes)
5
Press the +/- key

The parameter value can be changed.
6
Press the E key

Parameter 467 MOT 3 appears.
Selection of motor;
1 =DC1500, 2 =DC1550,
3 =DC1200, 4 =DC1250)
7
Press the +/- key

The parameter value can be changed.
8
Press the E key

Parameter 111 n2 appears.
(Maximum speed)
9
Press the +/- key

The parameter value can be changed.
10
Press the E key

Parameter 161 drE 0 appears.
(Direction of motor rotation)
11
Press the +/- key

The parameter value can be changed.
12
Press the E key

Parameter 270 PGm 0 appears.
(Type of position sensor)
13
Press the +/- key

The parameter value can be changed.
14
Press the E key

Parameter 272 trr 01000 appears.
(Transmission Ratio)
15
Press the +/- key

The parameter value can be changed.
16
If parameter 270 =0 or 5, or the check of the
transmission ratio is already done, continue with
Point 25.
17
Press the E key

PULY Ab620A is displayed.
Check the transmission ratio
18
Move pedal forwards
Let the drive run until ready (rdy) is displayed.
For a maximum speed that is too high, an error
message A12 is generated. Push button E as
often as needed until parameter 111 (Point 12) is
reached again to set the permitted maximum
speed.
19
Press pedal to position 0
(neutral)
The check is complete.
20
When parameter 270 ≠ 6, continue with Point
25.
21
PoS 0 o is displayed (o is red).
(Setting the reference position)
22
Rotate the hand wheel in the running direction until o extinguishes *.
Set reference position (e.g. height of the stitch plate, lower dead point).
23
Press the E key

Parameter 451 P1E appears
(Position 1 leading edge,
position 1 trailing edge is
automatically set 60° higher)
24
Turn the hand wheel

Set position 1 (at least 1 rotation *).
25
Or press the +/- key

The parameter value can be changed.
26
Press the E key

Parameter 453 P2E appears.
(Position 2 leading edge,
position 2 trailing edge is
automatically set 60° higher)
27
Turn the hand wheel

Set position 2 (at least 1 rotation *).
28
Or press the +/- key

The parameter value can be changed.
29
Upon pressing the E key once more the program returns to parameter 290!
30
Press the P key twice

The system exits the SIR routine.
*) All operations carried out by turning the hand wheel must always be carried out in the direction of rotation set up on the
machine. Under no circumstances should you turn against the machine direction.
