Efka AB620A5035 - Page 63

- AB620A5035 Instruction Manual
- 63 -
Mode 5 (chainstitch)
Mark
Function
Parameters
Control
V810
V820
FAm
SSt
Mode 5
Softstart
Start stitch condensing
End stitch condensing
On
On
290 =5
134 =1
Key E
Key +
Key 1
Key 2
Key 1
Key 4
n1
n2
n3
n4
n6
n7
Positioning speed
Maximum speed
Start stitch condensing speed
End stitch condensing speed
Softstart speed
Trimming speed
110
111
112
113
115
116
c1
c3
c4
SSc
t1
t3
t4
t5
kdF
kd1-kd4
kt1-kt4
Stitch counting of start stitch condensing
Stitch counting of end stitch condensing
Stitch counting at the seam end without stitch regulator
Softstart stitches
Delay until speed release after start backtack
Start delay from lifted sewing foot
Full power of sewing foot lifting
Pulsing of sewing foot lifting
Switch-on delay of sewing foot lifting
Delay times of outputs M1...M4
ON periods of outputs M1...M4
001
002
003
100
200
202
203
204
288
280/2/4/6
281/3/5/7
