Mode 5, 6 or 7 (function “unlocking the chain”)
Mark
Function
Parameters
Control
V810
V820
FAm
drE
Frd
in7
in8
in..
Mode 5
Direction of motor rotation
Reverse motor rotation
Basic position 2
End stitch condensing and thread trimmer *)
Machine run blockage effective with open
contact
Automatic speed n12 without pedal
Assign the function “unlocking the chain” to an
output
Right
On
On
290 =5
161 =0
182 =1
246 =6
247 =10
2..
Key >>
Key 4
Key 7
n1
n2
Positioning speed
Maximum speed
110
111
ird
drd
t3
t4
t5
tGn
dGF
Number of reversing increments
Switch-on delay of reverse motor rotation
Start delay from lifted sewing foot
Full power of sewing foot lifting
Pulsing of sewing foot lifting
Speed gate damping period
Speed gate 2
180
181
202
203
204
222
224 =1
*) When unlocking the chain, the functions “stitch condensing” and “thread trimmer” are suppressed!
